How To Install Jira on CentOS 8

How To Install Jira on CentOS 8

Install jira on centOS 8; Through this tutorial, we will learn how to install and configure jira on centOS 8.

How To Install Jira on CentOS 8

Just follow the following steps to install and configure jira on centOS 8:

  • Step 1 – Update System Packages
  • Step 2 – Install Java JDK
  • Step 3 – Install and Configure MySQL
  • Step 4 – Install Jira
  • Step 5 – Create a Systemd Service File for Jira
  • Step 6 – Configure Nginx as a Reverse Proxy
  • Step 7 – Access Jira Web Installation Wizard

Step 1 – Update System Packages

First of all open terminal and execute the following command on terminal to update system packages:

dnf update -y

Step 2 – Install Java JDK

Now, execute the following command on the terminal to install Java JDK to system:

dnf install java-11-openjdk java-11-openjdk-devel -y

Once Java is installed, verify the Java installation using the following command:

java -version

We should see the Java version in the following output:

openjdk version "11.0.13" 2021-10-19 LTS
OpenJDK Runtime Environment 18.9 (build 11.0.13+8-LTS)
OpenJDK 64-Bit Server VM 18.9 (build 11.0.13+8-LTS, mixed mode, sharing)

Step 3 – Install and Configure MySQL

Now, execute the following command on the terminal to install MySQL server:

dnf install @mysql

After the installation, start and enable the MySQL service with the following command:

systemctl start mysqld
systemctl enable mysqld

Next, edit the MySQL configuration file and tweak some settings:

nano /etc/my.cnf.d/mysql-server.cnf

Add the following lines inside the [mysqld] section:

default-storage-engine=INNODB
character_set_server=utf8mb4
innodb_default_row_format=DYNAMIC
innodb_log_file_size=2G
sql_mode = NO_AUTO_VALUE_ON_ZERO

Save and close the file, then restart the MySQL service to apply the changes:

systemctl restart mysqld

Next, log in to MySQL with the following command:

mysql

Once we are logged in, create a database and user for Jira:

CREATE DATABASE jira CHARACTER SET utf8mb4 COLLATE utf8mb4_bin;
CREATE USER 'jira'@'localhost' IDENTIFIED BY 'yourpassword';

Next, grant all required privileges to the Jira database with the following command:

GRANT SELECT,INSERT,UPDATE,DELETE,CREATE,DROP,REFERENCES,ALTER,INDEX on jira.* TO 'jira'@'localhost';

Next, flush the privileges and exit from MySQL using the command below:

FLUSH PRIVILEGES;
EXIT;

Step 4 – Install Jira

Now execute the wget command on terminal to download the latest version of Jira:

wget https://www.atlassian.com/software/jira/downloads/binary/atlassian-jira-software-8.20.2-x64.bin

Once the Jira is downloaded, make it executable with the following command:

chmod +x atlassian-jira-software-8.20.2-x64.bin

Next, run the downloaded binary file to start the installation:

./atlassian-jira-software-8.20.2-x64.bin

we will be asked to start the installation:

This will install Jira Software 8.20.2 on your computer.
OK [o, Enter], Cancel [c]

Press Enter key to start the installation. You will be asked to choose the installation option:

Click Next to continue, or Cancel to exit Setup.

Choose the appropriate installation or upgrade option.
Please choose one of the following:
Express Install (use default settings) [1], Custom Install (recommended for advanced users) [2, Enter], Upgrade an existing Jira installation [3]
1

Type 1 and press the Enter key to start with express installation. You will be asked to install Jira as a service:

Details on where Jira Software will be installed and the settings that will be used.
Installation Directory: /opt/atlassian/jira
Home Directory: /var/atlassian/application-data/jira
HTTP Port: 8080
RMI Port: 8005
Install as service: Yes
Install [i, Enter], Exit [e]

Just press the Enter key to continue. Once Jira is installed, you should see the following output:

Extracting files ...


Please wait a few moments while Jira Software is configured.

Installation of Jira Software 8.20.2 is complete
Start Jira Software 8.20.2 now?
Yes [y, Enter], No [n]
y

Type y and press the Enter key to start Jira. You should see the following output:

Please wait a few moments while Jira Software starts up.
Launching Jira Software ...

Installation of Jira Software 8.20.2 is complete
Your installation of Jira Software 8.20.2 is now ready and can be accessed
via your browser.
Jira Software 8.20.2 can be accessed at http://localhost:8080
Finishing installation ...

Next, download the Java MySQL connector using the command below:

wget https://dev.mysql.com/get/Downloads/Connector-J/mysql-connector-java-8.0.26.zip

Next, unzip the downloaded file using the following command:

dnf install unzip
unzip mysql-connector-java-8.0.26.zip

Next, copy the MySQL connector file to the appropriate directory:

cp mysql-connector-java-8.0.26/mysql-connector-java-8.0.26.jar /opt/atlassian/jira/lib

Step 5 – Create a Systemd Service File for Jira

Now, execute the following command on terminal to create a systemd service file to manage the Jira service:

nano /etc/systemd/system/jira.service

Add the following lines:

[Unit]
Description=Atlassian JIRA Software Server
After=network.target mysqld.service

[Service]
Type=forking
User=jira
ExecStart=/opt/atlassian/jira/bin/start-jira.sh
ExecStop=/opt/atlassian/jira/bin/stop-jira.sh
ExecReload=/opt/atlassian/jira/bin/start-jira.sh | sleep 60 | /opt/atlassian/jira/bin/stop-jira.sh

[Install]
WantedBy=multi-user.target

Save and close the file, then reload the systemd daemon with the following command:

systemctl daemon-reload

Next, stop the Jira script using the following command:

/opt/atlassian/jira/bin/stop-jira.sh

Next, start and enable the Jira service using systemd:

systemctl start jira
systemctl enable jira

Next, edit the Jira configuration file with the following command:

nano /opt/atlassian/jira/conf/server.xml

Modify the following section and include ProxyName and ProxyPort:

        <Connector port="8080" relaxedPathChars="[]|" relaxedQueryChars="[]|{}^\`"<>"
                   maxThreads="150" minSpareThreads="25" connectionTimeout="20000" enableLookups="false"
                   maxHttpHeaderSize="8192" protocol="HTTP/1.1" useBodyEncodingForURI="true" redirectPort="8443"
                   acceptCount="100" disableUploadTimeout="true" bindOnInit="false" scheme="http"
                   proxyName="jira.linuxbuz.com" proxyPort="80"/>

Save and close the file, then restart the Jira service to apply the changes:

systemctl restart jira

Step 6 – Configure Nginx as a Reverse Proxy

Now execute the following command on terminal to install and configure the Nginx as a reverse proxy for Jira.

First, install the Nginx package with the following command:

dnf install nginx -y

Next, start and enable the Nginx service using the following command:

systemctl start nginx
systemctl enable nginx

Next, create an Nginx virtual host configuration file:

nano /etc/nginx/conf.d/jira.conf

Add the following lines:

server {
    listen 80;
    server_name jira.linuxbuz.com;
    location / {
        proxy_set_header X-Forwarded-Host $host;
        proxy_set_header X-Forwarded-Server $host;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_pass http://jira.linuxbuz.com:8080;
        client_max_body_size 10M;
    }
}

Save and close the file, then edit the nginx.conf file and set the hash_bucket size:

nano /etc/nginx/nginx.conf

Add the following line below htttp {:

server_names_hash_bucket_size 64;

Save and close the file, then restart the Nginx service to apply the changes:

systemctl restart nginx

Step 7 – Access Jira Web Installation Wizard

Now, open web browser and access the Jira web installation wizard using the URL http://jira.linuxbuz.com. We should see the Jira setup page.
