Angular 14 Bar Chart Example

Angular 14 charts js bar chart; In this tutorial, we will learn how to create a bar chart using charts js library in angular 14 apps with the help of chart.js library.

Chart. js is a community maintained open-source library (it’s available on GitHub) that helps you easily visualize data using JavaScript. It’s similar to Chartist and Google Charts. It supports 8 different chart types (including bars, lines, & pies), and they’re all responsive.

Angular 14 Bar Chart Example

Use the following steps to implement bar chart using charts js in agnular 14 apps; as follows:

• Step 1 – Create New Angular App
• Step 2 – Install Charts JS Library
• Step 3 – Add Modules in Module.ts File
• Step 4 – Create Bar Chart on View File
• Step 5 – Add Code On bar-chart.Component ts File
• Step 6 – Start the Angular Bar Chart App

Step 1 – Create New Angular App

First of all, open your terminal and execute the following command on it to install angular app:

ng new my-new-app

Step 2 – Install Charts JS Library

Then install NPM package called ng2-charts chart.js –save for implement bar chart in angular app. So, You can install the packages by executing the following commands on the terminal:

npm install --save bootstrap

npm install ng2-charts chart.js --save

After that, open angular.json file and update the following code into it:

"styles": [
      "node_modules/bootstrap/dist/css/bootstrap.min.css",
      "src/styles.css"
]

Step 3 -Add Modules in Module.ts File

In this step, visit src/app directory and open app.module.ts file. And then add the following lines of into app.module.ts file:

import { ChartsModule } from 'ng2-charts';

@NgModule({
  declarations: [...],
  imports: [
    ChartsModule
  ],
  providers: [...],
  bootstrap: [...]
})

export class AppModule { }

Step 4 – Create Bar Chart on View File

In this step, create bar chart in angular 14 apps. So, visit src/app/ and bar-chart.component.htmland update the following code into it:

<div class="chart-wrapper">
    <canvas baseChart
    [datasets]="barChartData"
    [labels]="barChartLabels"
    [options]="barChartOptions"
    [plugins]="barChartPlugins"
    [legend]="barChartLegend"
    [chartType]="barChartType">
  </canvas>
</div>

Step 5 – Add Code On bar-chart.Component ts File

In this step, visit the src/app directory and open bar-chart.component.ts. Then add the following code into component.ts file:

import { Component } from '@angular/core';
import { ChartOptions, ChartType, ChartDataSets } from 'chart.js';
import { Label } from 'ng2-charts';

@Component({
  selector: 'app-bar-chart',
  templateUrl: './bar-chart.component.html',
  styleUrls: ['./bar-chart.component.css']
})

export class BarChartComponent {

  barChartOptions: ChartOptions = {
    responsive: true,
  };
  barChartLabels: Label[] = ['Apple', 'Banana', 'Kiwifruit', 'Blueberry', 'Orange', 'Grapes'];
  barChartType: ChartType = 'bar';
  barChartLegend = true;
  barChartPlugins = [];

  barChartData: ChartDataSets[] = [
    { data: [45, 37, 60, 70, 46, 33], label: 'Best Fruits' }
  ];

}

Step 6 – Start the Angular Bar Chart App

In this step, execute the following command on terminal to start angular bar chart app:

ng serve
