Angular 12/11 Date Range Picker Tutorial Example

Angular 11/12 date range picker component example. In this tutorial, you will learn how to use angular material to integrate date range picker in angular 11/12.

In this tutorial will guide you on how to integrate angular material for show date range picker in angular 11/12 app.

Angular 12/11 Date Range Picker Example

Follow the following steps and learn how to use date range picker in angular 11/12 app:

• Step 1 – Create New Angular App
• Step 2 – Install Angular Material Design
• Step 3 – Import Angular Material Module
• Step 4 – Add Code on View File
• Step 5 – Add Code On Component ts File
• Step 6 – Start Angular App

Step 1 – Create New Angular App

First of all, open your terminal and execute the following command on it to install angular app:

ng new my-new-app

Step 2 – Install Angular Material Design

In this step, you need to install angular material design for date range picker. so open terminal and execute the following command on it:

ng add @angular/material

After that, you will look like on your terminal:

Installing packages for tooling via npm.

Installed packages for tooling via npm.

? Choose a prebuilt theme name, or "custom" for a custom theme: Indigo/Pink

   [ Preview: https://material.angular.io?theme=indigo-pink ]

? Set up global Angular Material typography styles? Yes

? Set up browser animations for Angular Material? Yes

Step 3 – Import Angular Material Module

In this step, you need to import MatDatepickerModule, MatNativeDateModule, MatFormFieldModule and ReactiveFormsModule from angular/material. So visit src/app directory and open app.module.ts and then update the following code into it:

import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';

import { AppComponent } from './app.component';
import { BrowserAnimationsModule } from '@angular/platform-browser/animations';
import { MatDatepickerModule } from '@angular/material/datepicker';
import { MatNativeDateModule } from '@angular/material/core';
import { MatFormFieldModule } from '@angular/material/form-field';
import { ReactiveFormsModule } from '@angular/forms';

@NgModule({
  declarations: [
    AppComponent
  ],
    imports:      [
    BrowserModule,
    BrowserAnimationsModule,
    MatDatepickerModule,
    MatNativeDateModule,
    MatFormFieldModule,
    ReactiveFormsModule ],
  providers: [],
  bootstrap: [AppComponent]
})
export class AppModule { }

Step 4 – Add Code on View File

In this step, create simple reactive form to integrate date range picker in angular 11 app. So, visit src/app/app.component.html and update the following code into it:

<h1>Angular 11 Date Range Picker Example - Tutsmake.Com</h1>

<mat-form-field appearance="outline">
  <mat-label>Select Date Range</mat-label>

  <mat-date-range-input [rangePicker]="picker" [formGroup]="range">
    <input matStartDate placeholder="Start Date" formControlName="start">
    <input matEndDate placeholder="End Date" formControlName="end">
  </mat-date-range-input>

  <mat-datepicker-toggle matSuffix [for]="picker"></mat-datepicker-toggle>

  <mat-date-range-picker #picker></mat-date-range-picker>
</mat-form-field>

<h3>Start: {{range.value.start | date}} End: {{range.value.end | date}}</h3>

Step 5 – Add Code On Component ts File

In this step, visit the src/app directory and open app.component.ts. Then add the following code into component.ts file:

import { Component } from '@angular/core';
import { FormControl, FormGroup } from '@angular/forms';

@Component({
  selector: 'app-root',
  templateUrl: './app.component.html',
  styleUrls: ['./app.component.css']
})
export class AppComponent {
  title = 'my-app';

  range = new FormGroup({
    start: new FormControl(),
    end: new FormControl()
  });
}

Step 6 – Start Angular App

In this step, execute the following commands on terminal to start angular app:

ng serve
