Laravel 7 Google Bar Chart Example From Scratch

Laravel 7 Google Bar Chart Example From Scratch

Laravel 7 google bar chart tutorial from scratch. Here, you will learn how to implement google bar chart in laravel app from scratch.

As well as how to display dynamic data on google bar charts in laravel.

And also you can fetch month-wise data and display month-wise data in google bar chart for analytics in laravel app.

This tutorial will help you on how to implement google bar chart in laravel from scratch.

Google Bar Chart in Laravel

Follow the below steps and implement google bar chart in laravel app:

  • Step 1: Install Laravel App
  • Step 2: Add Database Details
  • Step 3: Generate Migration & Model File
  • Step 4: Add Route
  • Step 5: Create Controller
  • Step 6: Create Blade File
  • Step 7: Run Development Server

Step 1: Install Laravel App

In this step, you need to run below command to download or install fresh laravel setup into your machine for creating a laravel google bar chart app. So open your terminal and run the following command:

composer create-project --prefer-dist laravel/laravel blog

Step 2: Add Database Configuration

In this step, you need to navigate your laravel google bar chart app project root directory. And open .env file. Then add database detail like below:

DB_CONNECTION=mysql
DB_HOST=127.0.0.1
DB_PORT=3306
DB_DATABASE=Enter_Your_Database_Name
DB_USERNAME=Enter_Your_Database_Username
DB_PASSWORD=Enter_Your_Database_Password

Step 3: Generate Migration & Model File

In this step, you need to run the below command to create model and migration file. So open your terminal and run the following command:

php artisan make:model Order -fm

Then navigate to app directory and open Order.php file. And add the following code into your Order.php file:

<?php

namespace App;

use Illuminate\Database\Eloquent\Model;

class Order extends Model
{
    protected $guarded = [];
}

After that navigate to database/migrations/ and open create_orders_table.php file and update the following code:

Schema::create('orders', function (Blueprint $table) {
    $table->id();
    $table->string("product_name")->nullable();
    $table->string("product_id")->nullable();
    $table->string("price")->nullable();
    $table->timestamps();
});

Then open your terminal and run the following command:

php artisan migrate

After that, navigate to database/factories folder and open OrderFactory.php file. And the following code into your OrderFactory.php file:

<?php

/** @var \Illuminate\Database\Eloquent\Factory $factory */

use App\Order;
use Faker\Generator as Faker;

$factory->define(Order::class, function (Faker $faker) {
    return [
        "product_name"          =>  $faker->word,
        "product_id"            =>   $faker->numberBetween(1,100),
        "price"                =>  $faker->numberBetween(1, 100),
    ];
});

Then open your terminal again, and run the following command to generate fake data into your database in laravel:

 php artisan tinker  //then  factory(\App\Order::class,100)->create()

Step 4: Add Route

In this step, navigate to routes folder and open web.php file. Then add the following route into your web.php file:

Route::get("google-bar-chart", "OrderController@index");

Step 5: Create Controller

In this step, open your terminal again and run the following command to create controller named OrderController.php:

php artisan make:controller OrderController

Then Navigate to app/http/controller folder and open OrderController.php. And add the following code into your OrderController.php file:

<?php

namespace App\Http\Controllers;

use Illuminate\Http\Request;
use App\Order;

class OrderController extends Controller
{
    public function index()
    {
       $orders = Order::all();
       return view('google-bar-chart',['orders' => $orders]);
    }
}

Step 6: Create Blade File

In this step, navigate to /resources/views/ folder and create one blade view file name google-bar-chart.blade.php. And add the following code into your google-bar-chart.blade.php file:

<!doctype html>
<html lang="en">
  <head>
    <title>Laravel Google Bar Chart Example Tutorial</title>
    <meta charset="utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1, shrink-to-fit=no">
    <link rel="stylesheet" href="https://stackpath.bootstrapcdn.com/bootstrap/4.3.1/css/bootstrap.min.css">

    <script src="https://code.jquery.com/jquery-3.3.1.slim.min.js"></script>

    <script src="https://cdnjs.cloudflare.com/ajax/libs/popper.js/1.14.7/umd/popper.min.js"></script>

    <script src="https://stackpath.bootstrapcdn.com/bootstrap/4.3.1/js/bootstrap.min.js"></script>

    <script type="text/javascript" src="https://www.gstatic.com/charts/loader.js"></script>

</head>
  <body>
    <h2 style="text-align: center;">Laravel Google Bar Charts Example Tutorial - Tutsmake.com</h2>
    <div class="container-fluid p-5">
    <div id="barchart_material" style="width: 100%; height: 500px;"></div>
    </div>

    <script type="text/javascript">

      google.charts.load('current', {'packages':['bar']});
      google.charts.setOnLoadCallback(drawChart);

      function drawChart() {
        var data = google.visualization.arrayToDataTable([
            ['Order Id', 'Price', 'Product Name'],

            @php
              foreach($orders as $order) {
                  echo "['".$order->id."', ".$order->price.", ".$order->Product_name."],";
              }
            @endphp
        ]);

        var options = {
          chart: {
            title: 'Bar Graph | Price',
            subtitle: 'Price, and Product Name: @php echo $orders[0]->created_at @endphp',
          },
          bars: 'vertical'
        };
        var chart = new google.charts.Bar(document.getElementById('barchart_material'));
        chart.draw(data, google.charts.Bar.convertOptions(options));
      }
    </script>

</body>
</html>

Step 7: Run Development Server

Finally, you need to run the following PHP artisan serve command to start your laravel google bar chart app:

php artisan serve

If you want to run the project diffrent port so use this below command

php artisan serve --port=8080

Now, you are ready to run laravel google bar chart app. So open your browser and hit the following URL into your browser:

http://localhost:8000/google-bar-chart
